Centrifugal pump
Performance
- Hydraulically driven centrifugal pump
- Single rate across entire toolbar
- Single row section control
- Row by row flow sensors
- Rate range from 3-20 GPA
Options
- Notched fertilizer openers
- Liquid fertilizer tube in furrow
Models
Fertilizer pump options
- John Blue piston pump option with flow dividers*
- Hydraulically driven centrifugal pump (4805) to allow section shut-off and variable rate capability.
*Option includes pump mounting bracket, sprockets, drive components and flow divider.
Fertilizer Opener Options
Notched single disc
Liquid or Dry
- Notched 40 cm diameter blade
- Adjustable down pressure – depth range 2.5 cm – 10 cm
- For no-till and conventional tillage
- Optional depth gauge wheel for conventional till situations
Heavy duty single disc
Liquid or Dry
- 75 cm diameter blade
- Adjustable down pressure – depth range 5 cm – 12.75 cm
- For no-till or conventional tillage, harsh conditions, higher application rates, and rocky soil
Double disc
Liquid or Dry
- 38 cm diameter V-blade
- Adjustable coil spring down pressure
- Accurate fertilizer placement
- For conventional tillage
- Plant at speeds up to 10 km/h
In-furrow
Liquid
- Maximize fertilizer effectiveness with drop tubes behind row unit seed tubes to deliver liquid fertilizer directly in the furrow
- Very low fertilizer flow rate for pop-up applications
- For any tillage situation—used with low fertilizer rates and lower salt content fertilizers
